Description
True Refrigeration TUC-72-HC~SPEC3 Description
The True TUC-72-HC~SPEC1 Spec Series undercounter refrigerator has an extra-large evaporator coil balanced with a high-horsepower compressor and large condenser to maintain a set cabinet temperature between 33 and 38 degrees Fahrenheit. Because the evaporator fan motors are cast iron and self-lubricating, they can provide low-velocity, high-volume airflow, while the large fan blades are useful for fast temperature recovery and short runtimes in busy kitchens. Constructed of stainless steel, the cabinet has coved corners and 5-inch-diameter stem castors with locks on the front set. Designed with a 36-inch work surface height, the cabinet and doors are insulated with high-density polyurethane.
To match the cabinet interior, the stainless steel doors on the True TUC-72-HC~SPEC1 refrigerator are lined with clear-coated aluminum. These doors are self-closing to contain cold air and have a 90-degree, stay-open feature to facilitate stocking. Magnetic gaskets line the door frames and can be removed for cleaning. Its six shelves are adjustable in 1/2-inch increments and include four chrome-plated shelf clips each. Resisting corrosion, these shelves are made of PVC-coated wire and have support pilasters made of stainless steel. For streamlined installation, this unit is completely pre-wired at the factory and ready for final connection.
Product Details
- Part of the Spec Series
- Temperature holding range: 33-38 degrees F
- 6 shelves made of heavy-duty, PVC coated wire
- Shelves adjustable in 1/2-in. increments
- Each shelf includes 4 chrome-plated clips
- Electronic temperature control with digital display
- Stainless steel cabinet is insulated with polyurethane
- Lockable, 5-in.-diameter stem castors
- 36-in. work surface height
- Self-closing doors swing within cabinet dimensions
- Aluminum-lined doors include a 90-degree, stay-open feature
- Gaskets are magnetic and can be removed without tools for efficient cleaning
- Capillary tube system uses R134A refrigerant
- Factory-balanced refrigeration system with guided airflow provides uniform temperatures
- Cast iron fan motors are sealed and self-lubricating, ensuring fast temperature recovery and short run times
- Large fan blades operate at low velocity and high volumes
- Evaporator is epoxy coated to prevent rust
- Heavy-duty, 16-ga. top
- 20-ga. doors
- Countertop front is flush with front of doors
Dimensions & Utilities
- Shelves: 219/16 in. W x 16 in. D
- Overall: 725/16 in. W x 3215/16 in. D x 36 in. H
- 8.5 A, 1/3 HP
- 115 V/60 Hz/1 ph, 7-ft. cord with a NEMA 5-15P plug
SPEC SERIES Undercounter Refrigerator, 33 – 38°F, SPEC Package 3 includes: 16-ga. stainless steel top, (3) heavy-duty stainless steel doors, steel handles, door lock standard, (6) PVC coated adjustable wire shelves, electronic temperature control with digital temperature display, stainless steel sides & back, stainless steel interior, 5″ castors, R290 Hydrocarbon refrigerant, 1/4 HP, 115v/60/1-ph, 4.0 amps, NEMA 5-15P, cULus, UL EPH Classified, CE, Made in USA
