Description
The True TSD-47G-HC-LD TSD series reach-in two-section refrigerator has a self-contained capillary tube system that uses eco-friendly R290 hydrocarbon refrigerant. Because the evaporator and condenser fan motors are electronically commutated, the motors move a consistent volume of air while producing little heat, and this optimized design reduces energy consumption and provides motor reliability. Due to the condensing unit’s low positioning, it stays within reach for convenient maintenance, and the compressor runs in the coolest, most grease-free area of the kitchen, freeing up storage space on top of the unit.
Because of its glass doors and LED lighting, the True TSD-47G-HC-LD reach-in refrigerator shows off product to customers. Its PVC-coated shelves and stainless steel floor resist corrosion in case of leaks, while the exterior surfaces are rust-resistant stainless steel, GalFan-coated steel, and anodized aluminum. Doors slide open efficiently because they are counterbalanced, and close by themselves to prevent cold air from escaping. Keeping cold temperatures inside, polyurethane insulation is foamed in the walls, and along with a heavy-duty frame rail, the insulation reinforces the cabinet structure.
Product Details
- Part of the TSD series
- 6 heavy-duty, PVC-coated wire shelves
- Shelves are adjustable in 1⁄2-in. increments
- Each shelf includes 4 chrome-plated clips
- Cabinet interior matches shelf support pilasters
- Safety-shielded, LED lighting brightens interior
- Double-pane, thermal glass provides product visibility
- Smooth, positive door closure
- Doors self-close with counterbalanced weight system
- 12-in.-long plastic handle on each door
- Durable stainless steel V-channel and stainless steel bearings
- Interior has attractive, clear-coated aluminum liner
- Coved corners on stainless steel floor
- Frame rail is welded for strength and coated with black powder for corrosion protection
- Insulated with high-density polyurethane foam
- Stainless steel front and anodized aluminum ends
- Steel back is coated with corrosion-resistant GalFan
- 6-in. legs raise unit off the floor
- NSF/ANSI Standard 7 compliant for open food products
- cULus and UL-EPH listed
- Made with innovation in the U.S.
State-of-the-Art Refrigeration System
- Corrosion potential is reduced by epoxy coating on the evaporator
- Electronically commutated evaporator and condenser fan motors move a consistent volume of air, producing little heat by operating at high-peak efficiencies
- Optimized design reduces energy consumption and provides motor reliability
- Capillary tube system is factory-engineered and self-contained, using environmentally friendly R290 hydrocarbon refrigerant
- Convenient maintenance is provided by bottom-mounted condensing unit
- Compressor runs in cool, grease-free kitchen area
- Storage area available on top of unit
- Temperature holding range: 33-38 degrees F
- Exterior display shows interior temperature
| Compressor Location | Bottom |
| Cubic Feet | 47 |
| Depth (in) | 29.63 |
| Door Type | Glass |
| Doors | Full |
| Evaporator Type | Capillary Tube |
| Height (in) | 78.38 |
| Hertz | 60 |
| Interior Material | Aluminum |
| NEMA | 5-15P |
| Phase | 1 |
| Product Type | Commercial Refrigeration |
