Scotsman C0630SW-32/B530S 633 lb Half Cube Ice Maker w/ Bin – 536 lb Storage, Water Cooled, 208-230v/1ph

The Scotsman C0630SW-32/B530S ice maker with bin has straightforward controls with a diagnostic module and operating status indicator lights. Internal components are accessible behind the self-aligning front panel, and its polyethylene interior liner resists scuffs and scratches. A one-touch cleaning feature and antimicrobial protection keep the unit sanitary. The bin door has a spring-loaded design and concealed hinges to further aid in cleanup. This Scotsman C0630SW-32/B530S ice maker and bin can produce 633 pounds in 24 hours and store 536 pounds. An ice scoop is included along with an integrated holder.

Ice Maker Details

• 633-lb. ice production capacity
• 573-lb. AHRI-certified ice production capacity
• Half-cube ice size: 0.875 in. x 0.875 in. x 0.375 in.
• 1-touch cleaning
• Antimicrobial agent on the internal surfaces reduces bacteria growth
• WaterSense purge control eliminates scale buildup
• AutoAlert lights indicate the operating status
• Diagnostic Smart-Board module
• QR code can be scanned to provide information for service and warranty history
• Accessible components sit behind the self-aligning front panel
• Harvest Assist transfers ice into the bin
• Water-cooled condenser
• R404A refrigerant
• 12,700 BTU
• Required ambient air temperature: 50-100 degrees F
• Required incoming water temperature: 40-100 degrees F
• Required incoming water pressure: 20-80 PSIG

Bin Details

• 536-lb. storage capacity
• Hinges in the spring-loaded door are hidden to facilitate cleaning
• Baffle can be removed (no tools required)
• Recessed drain fitting enhances installation flexibility
• Ice scoop is included with a built-in holder
• Polyethylene liner is resistant to scratches and scuffs
• Metallic exterior finish

Dimensions & Utilities

• Ice Maker
  • 30.7 in. W x 24 in. D x 23.01 in. H
  • 9.8 A, 4.1 kW
  • 208-230 V/60 Hz/1 ph
• Bin
  • 30.5 in. W x 34 in. D x 50 in. H

From The Manufacturer

C0630SW-32 Ice Maker: Prodigy Plus Ice Maker, cube style, water-cooled, self-contained condenser, production capacity up to 633 lb/24 hours at 70°/50° (573 lb AHRI certified at 90°/70°), stainless steel finish, small cube size, 208-230v/60/1-ph, 9.8 amps, cULus, NSF, CE; B530S Ice Bin: Ice Bin, top-hinged front-opening door, 536 lb application capacity, for top-mounted ice maker, polyethylene liner, metallic finish exterior, includes 6″ legs, NSF

*Image may not depict product color, inclusions or accessories.
