Description
Scotsman C0630SA-32/B530S
Producing as much as 640 pounds per day, the Scotsman C0630SA-32/B530S Prodigy Plus ice maker with bin makes half-cube ice for drinks. Operating status is shown through indicator lights, while diagnostic information is displayed on the smart module. Operators can check service and warranty information by scanning the QR code, while an ice scoop and built-in holder come with the Scotsman C0630SA-32/B530S ice maker and bin. Holding 536 pounds, the bin has a spring-loaded door and hidden hinges that facilitate cleaning.
Ice Maker Details
- 640-lb. ice production capacity
- 474-lb. AHRI-certified ice production capacity
- Half-cube ice size: 0.875 in. x 0.375 in. x 0.875 in.
- Smart-Board module provides diagnostic feedback
- Operating status shown by AutoAlert indicator lights
- QR code can be scanned to show service and warranty information
- 1-touch cleaning
- Antimicrobial agent slows down bacteria growth between cleanings
- WaterSense purge control removes buildup of scale
- Front panel provides component access
- Harvest Assist technology ensures ice efficiently moves into the bin
- Part of the Prodigy Plus series
- Air-cooled condensing unit
- R404A refrigerant
- 12,700 BTU
- Required ambient air temperature: 50-100 degrees F
- Required incoming water temperature: 40-100 degrees F
- Required incoming water pressure: 20-80 PSIG
Bin Details
- 536-lb. storage capacity
- Spring-loaded door is convenient to open
- Hidden hinges eliminate crevices to simplify cleaning
- Baffle is removable without tools
- Recessed drain fitting provides installation flexibility
- Ice scoop is included with scoop holder
- Metallic finish
Dimensions & Utilities
- Ice Maker
- 30.7 in. W x 24 in. D x 23.01 in. H
- 11 A, 5.63 kW
- 208-230 V/60 Hz/1 ph
- Bin
- 30.5 in. W x 34 in. D x 50 in. H
From The Manufacturer
C0630SA-32 Ice Maker: Prodigy Plus Ice Maker, cube style, air-cooled, self-contained condenser, production capacity up to 640 lb at 70°/50° (474 lb AHRI certified at 90°/70°), stainless steel finish, small cube size, 208-230v/60/1-ph, 11.0 amps, cULus, NSF, CE; B530S Ice Bin: Ice Bin, top-hinged front-opening door, 536 lb application capacity, for top-mounted ice maker, polyethylene liner, metallic finish exterior, includes 6″ legs, NSF
*Image may not depict product color, inclusions or accessories.
