Description
Scotsman C0630MW-32/B530S
The Scotsman C0630MW-32/B530S Prodigy Plus ice maker with bin can produce 633 pounds per day with a water-cooled condenser. Making full-cube ice, the unit is ideal for restaurants and bars that sell a lot of drinks. Employees can keep up with the unit through the diagnostic module and operating status indicator lights. When issues arise, the operator can scan the QR code for instant connection to service information and warranty history.
An antimicrobial agent in the ice machine head slows bacteria growth, while purge control helps eliminate scale. This Scotsman C0630MW-32/B530S ice maker with bin uses Harvest Assist technology to move ice. Holding 536 pounds, the bin has a spring-loaded door for convenient opening. Hidden hinges on this door eliminate crevices that can hinder cleaning.
Ice Maker Details
- 633-lb. ice production capacity
- 573-lb. AHRI-certified ice production capacity
- Full-cube ice size: 0.875 in. x 0.875 in. x 0.875 in.
- Smart-Board diagnostic module
- AutoAlert indicator lights show operating status
- Scannable QR code provides warranty and service information
- 1-touch cleaning button
- Antimicrobial agent protects against bacteria growth
- WaterSense purge control helps remove scale buildup
- Self-aligning front panel provides component access
- Harvest Assist technology efficiently moves ice to bin
- Part of the Prodigy Plus series
- Water-cooled condenser
- R404A refrigerant
- 12,700 BTU
- Required ambient air temperature: 50-100 degrees F
- Required incoming water temperature: 40-100 degrees F
- Required incoming water pressure: 20-80 PSIG
Bin Details
- 536-lb. storage capacity
- Spring-loaded door
- Hidden door hinges eliminate hard-to-clean crevices
- Baffle is removable without tools
- Recessed drain fitting enhances installation flexibility
- Ice scoop is included with integrated holder
- Metallic finish
Dimensions & Utilities
- Ice Maker
- 30.7 in. W x 24 in. D x 23.01 in. H
- 9.8 A, 4.1 kW
- 208-230 V/60 Hz/1 ph
- Bin
- 30.5 in. W x 34 in. D x 50 in. H
From The Manufacturer
C0630MW-32 Ice Maker: Prodigy Plus Ice Maker, cube style, water-cooled, self-contained condenser, production capacity up to 633 lb/24 hours at 70°/50° (573 lb AHRI certified at 90°/70°), stainless steel finish, medium cube size, 208-230v/60/1-ph, 9.8 amps, cULus, NSF, CE; B530S Ice Bin: Ice Bin, top-hinged front-opening door, 536 lb application capacity, for top-mounted ice maker, polyethylene liner, metallic finish exterior, includes 6″ legs, NSF
*Image may not depict product color, inclusions or accessories.
