Description
Scotsman C0530SA-1/B530S
The Scotsman C0530SA-1/B530S Prodigy Plus ice maker and bin has an air-cooled condenser and can produce 525 pounds of ice in 24 hours. Its front-located air filter enables more air flow than a side- or rear-located filter, and AutoAlert lights inform the user when descaling, sanitizing, and other maintenance should be performed. To provide a constant supply, the Harvest Assist feature pushes ice into the bin with gas and a probe. The one-touch cleaning process and an antimicrobial agent guard the ice machine from bacteria.
A stainless steel and metallic finish with polyurethane foam insulation provides the Scotsman C0530SA-1/B530S ice machine with structural support while retaining cold temperatures. Its interior is lined with polyethylene to reduce scratches and scuffs. A scoop with a built-in holder is included to keep the scoop out of the ice. For efficient installation, its drain fitting is recessed, and its spring-loaded door has hidden hinges for convenient opening and closing. This unit can hold 536 pounds of ice.
Ice Machine Details
- Part of the Prodigy Plus series
- 525-lb. daily ice production capacity
- 380-lb. AHRI-certified daily ice production capacity
- Half-cube ice size: 0.875 in. x 0.875 in. x 0.375 in.
- Air-cooled condenser uses R404A refrigerant
- Air filter is located on the front for maximum efficiency
- Stainless steel finish
- Cleaning process begins with the push of a button
- AutoAlert lights notify users when maintenance is necessary
- WaterSense purge control monitors and adjusts water quality to reduce scale buildup
- Harvest Assist feature guides ice into the bin with a probe and gas
- Front panel is removable for internal component access
- QR code connects the user to warranty and technical information
- Antimicrobial technology protects the unit between cleanings
- 7,900 BTU
- Required ambient air temperature: 50-100 degrees F
- Required incoming water temperature: 40-100 degrees F
- Required incoming water pressure: 20-80 PSI
Ice Bin Details
- 536-lb. ice storage capacity
- Metallic finish is corrosion resistant
- Polyurethane foam insulation preserves ice by retaining cold air
- Polyethylene interior minimizes scratches
- Ice scoop is included with a built-in holder
- Removable baffle does not require tools
- Recessed drain fitting aids in installation
- Spring-loaded door with hidden hinges
Dimensions & Utilities
- Ice Maker
- 30.7 in. W x 24 in. D x 23 in. H
- 15.2 A, 5.8 kW
- 115 V/60 Hz/1 ph
- Ice Bin
- 30.5 in. W x 34 in. D x 50 in. H
From The Manufacturer
C0530SA-1 Ice Maker: Prodigy Plus Ice Maker, cube style, air-cooled, self-contained condenser, production capacity up to 525 lb/24 hours at 70°/50° (380 lb AHRI certified at 90°/70°), stainless steel finish, small cube size, 115v/60/1-ph, 15.2 amps, cULus, NSF, CE; B530S Ice Bin: Ice Bin, top-hinged front-opening door, 536 lb application capacity, for top-mounted ice maker, polyethylene liner, metallic finish exterior, includes 6″ legs, NSF
*Image may not depict product color, inclusions or accessories.
