Scotsman C0522SW-1/B530P/KBT27 480 lb Half Cube Ice Maker w/ Bin – 536 lb Storage, Water Cooled, 115v

The Scotsman C0522SW-1/B530P/KBT27 Prodigy Plus ice machine and bin has a water-cooled condenser and can make 480 pounds of ice in 24 hours. When sanitizing, descaling, and other maintenance is needed, AutoAlert lights notify the user. A QR code placed on the front of the machine connects the user with warranty and technical service information. Its WaterSense feature adjusts the incoming water quality to minimize scale buildup. To ensure a consistent supply of ice, the Harvest Assist feature guides ice into the bin with hot gas and a probe. The cleaning process activates with a single touch, and a built-in antimicrobial agent guards the unit between cleanings.

The Scotsman C0522SW-1/B530P/KBT27 ice maker and bin has a 536-pound ice storage capacity, and its rotocast plastic construction is corrosion resistant. A scoop is included with a holder to keep the scoop out of the ice. Its recessed drain fitting provides flexibility when installing the bin, and a KBT27 adapter kit is included to properly fit it to the machine. Its door is spring loaded for smooth operation, while hidden door hinges eliminate hard-to-clean crevices.

Ice Maker Details

• Part of the Prodigy Plus series
• 480-lb. daily ice production
• 409-lb. AHRI-certified daily ice production
• Water-cooled condenser uses R404A refrigerant
• AutoAlert lights display the operating status
• Front-located QR code provides technical and warranty information
• 1-touch cleaning feature
• Removable front panel
• Water quality and scale buildup are monitored with a WaterSense feature
• Harvest Assist feature ensures a constant supply of ice
• Unit is protected between cleanings with a built-in antimicrobial agent
• Half-cube ice size: 0.875 in. x 0.875 in. x 0.375 in.
• Required ambient air temperature: 50-100 degrees F
• Required incoming water temperature: 40-100 degrees F
• Required incoming water pressure: 20-80 PSI
• 7,900 BTU

Ice Bin Details

• 536-lb. ice storage capacity
• Rotocast plastic construction resists corrosion
• Removable baffle (does not require tools)
• Built-in scoop holder with a scoop included
• Recessed drain fitting supports installation
• Spring-loaded door with hidden hinges
• KBT27 adapter kit fits the bin to the machine

Dimensions & Utilities

• Ice Maker
  • 22.67 in. W x 25.15 in. D x 23 in. H
  • 11.9 A, 4.48 kW
  • 115 V/60 Hz/1 ph
• Ice Bin
  • 30 in. W x 34 in. D x 50 in. H

From The Manufacturer

C0522SW-1 Ice Maker: Prodigy Plus Ice Maker, cube style, water-cooled, self-contained condenser, production capacity up to 480 lb/24 hours at 70°/50° (409 lb AHRI certified at 90°/70°), stainless steel finish, small cube size, 115v/60/1-ph, 11.9 amps, cULus, NSF, CE; B530P Ice Bin: Ice Bin, top-hinged front-opening door, 536 lb application capacity, for top-mounted ice maker, polyethylene liner, rotocast plastic construction, includes 6″ legs, NSF; KBT27 Ice Bin Top: Bin Top, for use with all 22″ cubers, flakers & nugget makers (except EH222) on B230, B330 & B530 bins

*Image may not depict product color, inclusions or accessories.
