Description
• Rack capacity: 19.75” x 19.75” (500 mm x 500 mm)
• Complete operating cycle: Two programmable cycles (1-3 Min)
• Wash tank capacity: 7.25 U.S. gallons (5.50 U.S. Ltl)
• Wash tank element: 2800 watts
• Wash temperature: 150°F (65°C)
• Booster capacity: 2.20 U.S. gallons (8 litres)
• Booster element: 4000 watts
• Booster (water) temperature: 185°F – 194°F (85°C – 90°C)
• Power supply: 208-240/60/1
• Amperage: 22.3 amps
• Maximum power rating: 4550 watts
• Water consumption: 0.79 U.S. gallons per cycle (3 litres)
• Water consumption per hour: 25.9 U.S. gallons (98 litres max.)
• Water supply: 1/2“ hot water supply 140°F / 60°C
• Recommended pressure: 25 p.s.i. (dynamic) (PRV may be required)
• Water inlet connection: 3/4” male hose connector (hose included)
• Drain connection: 1” ID (25.4mm) max height 36” (915mm) (hose included)
• Shipping weight: 165 lbs (75 kg)
Product Specifications
Manufacturer | Jet-Tech |
Model | EV-18 |
Height | 34 |
Width | 23 |
Depth | 24 |
Weight | 165 |
Rack Size | 20″ X 20″ |
Construction | Stainless Steel |
Cabinet base | Fully Enclosed |
Tank Heat | Electric |
Energy Efficiency | ENERGY STAR® |
Temperature | High Temp With Booster |
