Description
Ice-O-Matic CIM0330FA/B110PS
A self-contained condenser and dual exhaust system makes the Ice-O-Matic CIM0330FA/B110PS ice maker with bin simple to install and suitable for inclusion in a wide variety of floor plans. It produces full-size ice cubes, making it useful for locations that often serve iced drinks, such as soda and tea. The unit is simple to operate and includes an LED display as well as one-touch controls for sanitizing and descaling.
The Ice-O-Matic CIM0330FA/B110PS full-cube ice machine head comes with a bin that can store as much as 854 pounds of ice at a time, enabling operators to meet demand during busy periods. The bin has a top-hinged, sloped front door and stands on adjustable 6-inch legs for stability. To preserve the cold temperature of stored ice, the bin is insulated with a polyethylene liner that resists corrosion and heat transfer.
Ice Maker Details
- Part of the Elevation Series
- Production capacity: 313 lbs./24 hours in ideal conditions
- AHRI production capacity: 244 lbs./24 hours
- Produces full-size ice cubes
- Cube dimensions: 7/8 in. x 7/8 in. x 7/8 in.
- Air-cooled
- Self-contained condenser
- Dual exhaust on top and side of unit
- Plastic food zone releases buildup
- Dishwasher-safe, snap-in pieces
- PURE ICE antimicrobial defense
- Smart display and notification lights are LED
- Control board designed with Universal Smart Harness
- Simple 1-touch sanitizing
- Built with BPA-free recyclable interior parts
- Ideal incoming water temperature: 40-100 degrees F
- Ideal ambient temperature: 50-100 degrees F
- Ideal water pressure: 20-80 PSIG
- Heat displacement: 4,400 BTU/hour
Ice Bin Details
- 854-lb. capacity
- Top-hinged, sloped front door
- Corrosion-resistant insulated polyethylene liner
- Exterior finish is rotocast aluminum
- Designed with 6-in. adjustable legs
Dimensions & Utilities
- Ice maker: 30.25 in. W x 24.25 in. D x 21.25 in. H
- Bin: 48 in. W x 31 in. D x 50 in. H
- 11 A, 6.69 kW
- 120 V/60 Hz/1 ph
- Potable water inlet: 3/8-in. FPT
- Water outlet: 3/4-in. FPT
- Electrical connection port: 7/8-in. diameter
- Electrical connection junction box: 7/8-in. diameter
Elevation Series Modular Cube Ice Maker w/ Bin, air-cooled, self-contained condenser, dual exhaust top/side air discharge, 30″ W, approximately 313 lb production/24 hours at 70°/50° (244 lb at 90°/70°), full-size cubes, PURE ICE built-in antimicrobial protection, LED status display, one touch sanitize/descaling controls, dishwasher safe food zone components, 115v/60/1-ph, 11.0 amps, cULus, NSF, CE; Ice Bin w/ Filler Panels: 854 lb storage capacity, 48″W x 31″D x 50″H, top-hinged, slope front door, for top-mounted ice maker, polyethylene interior, durable stainless finish exterior, 6″ legs, NSF
