Delfield GUF27P-S 27″ W Undercounter Freezer w/ (1) Section & (1) Door, 115v

The Delfield GUF27P-S Coolscapes undercounter freezer is designed for installation under a counter, providing additional storage space in prep areas and on cook lines. It has one section with a corrosion-resistant epoxy shelf. Made of stainless steel, the door can be reversed in the field to fit in different layouts. For product stocking and cabinet cleaning, this door has a self-closing hinge that can also stay open past 90 degrees.

The refrigeration system in this Delfield GUF27P-S undercounter freezer is rear mounted and has a front-breathing design that doesn’t require top or side clearances. This system keeps the temperature between -5 and 0 degrees Fahrenheit-a level the operator can set on the controller. Because the controls are electronic, they improve pull-down times to reduce compressor cycling, and with fewer cycles, the compressor uses less energy and has a longer lifespan. While this control system has an adaptive defrost that removes evaporator ice, the hot gas system eliminates evaporator condensate.

Product Details

• 6.5-cu.-ft. interior space
• 1 section
• 1 gray epoxy-coated shelf
• Stainless steel exterior top and front
• Aluminum sides
• Galvanized back and bottom
• Gray-coated interior sides have an anodized aluminum bottom
• High-density, foamed-in-place polyurethane insulation
• 180-degree door opening
• Field-reversible stainless steel door
• Smart door hinge self-closes at less than 90 degrees and stays open past that angle
• Integral door handle
• Removable magnetic door gasket seals in cold air
• Replaceable door opening heater
• 2 of the (4) 5-in. casters have brakes

Refrigeration System

• Temperature holding range: -5 to 0 degrees F
• Rear digital temperature display
• Electronic temperature control improves pull-down times to reduce compressor cycling
• Adaptive defrost keeps ice off the evaporator
• Hot gas system eliminates evaporator condensate
• Uses GreenGenius R290 hydrocarbon refrigerant
• Thermostatic expansion valve accurately meters refrigerant
• Rear-mounted design
• Front-breathing design eliminates need for top and side clearances

Dimensions & Utilities

• Interior: 24.90 in. W x 19.90 in. D x 22.20 in. H
• Overall: 27 in. W x 31.59 in. D x 36 in. H
• 2.6 A, 2.6 kW, ¹/₃ HP
• 115 V/60 Hz/1 ph, 8-ft. cord with a NEMA 5-15P plug

Coolscapes Undercounter/Worktable Freezer, one-section, 27″ W, 6.5 cubic feet, (1) stainless steel door, (1) gray epoxy coated shelf, stainless steel top and front, aluminum sides, galvanized back and bottom, gray coated aluminum interior sides & anodized aluminum bottom, 5″ casters (2 locking, 2 non-locking), rear-mounted refrigeration system, GreenGenius R290 Hydrocarbon refrigerant, 115v/60/1, 2.6 amps, 8′ cord, NEMA 5-15P, 1/3 HP, UL, cUL, NSF

Note: Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
