Delfield GUF27P-D 27″ W Undercounter Freezer w/ (1) Section & (2) Drawers, 115v

Providing cold storage without cutting into work space, the Delfield GUF27P-D Coolscapes undercounter freezer is engineered for placement under existing countertops in prep spaces. It has a single section separated into two drawers, which can hold 12 total sixth-size, 6-inch-deep pans. Handles are built into the drawers and have a removable gasket that seals cold air inside the cabinet.

The temperature in this Delfield GUF27P-D one-section undercounter freezer ranges from -5 to 0 degrees Fahrenheit, and operators can adjust this level on the electronic controller. This control system improves pull-down times for reduced compressor cycling, which reduces energy consumption and lengthens component lifespan. While the freezer has an adaptive defrost that keeps ice off the evaporator, the hot gas condensate system keeps the evaporator free of water.

Product Details

• 4.8-cu.-ft. interior space
• 1 section
• Can hold 12 sixth-size, 6-in.-deep pans (not included)
• 2 drawers
• Integral drawer handles
• Removable magnetic drawer gasket minimizes cold air escaping
• Replaceable heater for drawer openings
• Stainless steel exterior top and front
• Aluminum exterior sides
• Galvanized exterior back and bottom
• Gray-coated interior sides have an anodized aluminum bottom
• High-density polyurethane insulation is foamed in place for cold air retention
• (4) 5-in. casters; 2 with brakes

Refrigeration System

• Temperature holding range: -5 to 0 degrees F
• Rear-mounted digital temperature display
• Electronic temperature control ensures efficient pull-down times to reduce cycling of the compressor
• Adaptive defrost removes ice buildup on evaporator
• Hot gas condensate system for evaporator
• Eco-friendly GreenGenius R290 hydrocarbon refrigerant
• Thermostatic expansion valve meters refrigerant based on temperature
• Rear-mounted placement
• Front-breathing design doesn’t require top or side clearances

Dimensions & Utilities

• 27 in. W x 31.59 in. D x 36 in. H
• 2.60 A, 2.25 kW, ¹/₃ HP
• 115 V/60 Hz/1 ph, 8-ft. cord with a NEMA 5-15P plug

Coolscapes Undercounter/Worktable Freezer, one-section, 27″ W, 4.8 cubic feet, (2) drawers, holds (12) 1/6 size pans 6″ deep, stainless steel top and front, aluminum sides, galvanized back and bottom, gray coated aluminum interior sides & anodized aluminum bottom, 5″ casters (2 locking, 2 non-locking), rear-mounted refrigeration system, GreenGenius R290 Hydrocarbon refrigerant, 115v/60/1, 2.6 amps, 8′ cord, NEMA 5-15P, 1/3 HP, UL, cUL, NSF, ENERGY STAR

Note: Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
