Cleveland PGM3003 Description
The Cleveland PGM3003 floor model steamer has three compartments. Each section can hold four 18-inch-by-26-inch pans, and depending on their depth, they can accommodate four to eight 12-inch-by-20-inch pans. Operating pressure in the compartments is monitored by a gauge, while a timer tracks the cooking progress. When pressure is in the cavities, the interlock prevents the operator from opening the doors. To add durability, the steam cavity doors are made of cast aluminum with adjustable hinges. The Cleveland PGM3003 floor model steamer has a 36-inch cabinet base that is accessible through 36-inch doors.
Product Details
- Natural gas-heated boiler
- 3 compartments
- Compartment operating pressure: 5 PSI
- Compartment gauges for operating pressure
- Interlock does not allow doors to be opened when the compartments are pressurized
- Interlocked steam inlet valves and exhaust valves provide synchronous action
- Thermostatic traps release air and wet steam for 2 min.
- Manual controls
- Each compartment has a 60-min. mechanical timer with an audible signal
- Compartment doors are made of heavy-duty cast aluminum with adjustable hinges
- Door gaskets can be removed and replaced without tools
- 36-in. cabinet storage base with hinged doors
- Heavy-duty, rust-resitant stainless steel construction
- 6-in. adjustable legs have flanged feet
- High-limit pressure safety switch
- Safety valve
- 300,000 BTU
- Overall dimensions: 35.43 in. W x 37 in. D x 73.63 in. H
Pan Capacities
- (12) 18-in. x 26-in. bun pans
- (12) 12-in. x 20-in. x 6-in. cafeteria pans
- (18) 12-in. x 20-in. x 4-in. cafeteria pans
- (24) 12-in. x 20-in. x 2.5-in. cafeteria pans
Pressure Steamer, gas, 36″ cabinet base, (3) compartments, (8) 12″ x 20″ pan or (4) 18″ x 26″ pan capacity per compartment, manual controls, 60-minute mechanical timer, 6″ adjustable legs with flanged feet, stainless steel construction, 300,000 BTU
