Description
Cabinet construction
- Stainless steel cabinet construction
- Stainless steel interior and exterior (galvanized steel back & bottom).
- Cycolpentane Insulation – Contains no hydro-fluorocarbons (HFCs) and is environmentally friendly
- Epoxy coated wire shelves with adjustable shelving height.
- 4 shelves per compartment
- Four (4) 4” Diameter swivel casters with front brakes standard.
- Designed to accept full size roll-in racks for bun sheet pan (18”L x 26”D)
Refrigeration
- Hydrocarbon refrigerants (R-290) – increases energy efficiency by up to 25% compared to using HFC refrigerants. It is safer for the environment and does not cause ozone depletion.
- Front sliding refrigeration unit allows unit to be serviced without being moved.
- Self-contained system, bottom mounted compressor provides quick and easy maintenance
- Electrodeposition coated evaporator increases performance by maintaining the heat transfer rates over the life of the evaporator and reducing potential corrosion.
- Air guard on rear wall ensures proper air circulation and cooling.
- Innovative hot gas frame heating system reduces condensation and increases energy efficiency.
- Refrigerators have a temperature range between 33°F ~ 39°F
- Standard Fabric condensation
Doors
- Self closing doors (doors close at 90° or less)
- Automatic hold open door feature at 110°
- Durable door gasket with easy replacement.
- Lifetime guaranteed heavy duty all metal door handles. (Ni-Cr Plated)
- Door designed to open easily.
- Doors built with pressure relievers to eliminate vacuum pressure and allow easy door opening.
- Standard door locks
Design & Features
- Self-diagnostic digital temperature control & monitor system
- Digital display allows for easy monitoring
- Digital controls include automatic evaporator fan motor delay.
- Rounded corner design gives a stylish appearance and reduces chances of injury.
- Visual and audible door open alarm, alarm sounds when doors are not completely closed to protect against food spoilage
Lighting
- LED Interior lighting.
Standard
- NSF/ANSI Standard 7 compliant
Connection
- 9 ft long flexible three wire cord with molded plug
Optional Features & Accessories
- 2.5″ diameter casters available
- 6″ adjustable feet available
- Left hinged door available for single door models
- Additional shelves are available.
| Capacity | 23 cu. ft. |
| Exterior Dimensions ( L x D x H ) | 26 3/4 x 32 7/16 x 82 3/8 inch |
| Net Weight | 271 lb |
| Door | 1 |
| Shelves | 4 |
| Compressor | 1/4+ |
| Refrigerant | R-290 |
| Temperature Range | 33℉ ~ 39℉ |
| Input (Voltage / Hz / Phase) | AC 115V / 60Hz / 1 |
| Amps | 2 |
| Energy Consumption | 2.07 (kWh/day) |
